Specification Parameters

Thickness 0.1-3mm, width 600-2000mm, length cut as needed (usually 1-6m), single sheet weight is light (several kilograms to dozens of kilograms)

Thickness 0.1-3mm, width 600-2000mm, coil inner diameter is mostly 508mm or 610mm, single coil weight 5-20 tons, can be cut into any length

Uses

Directly used in scenarios requiring single plates such as home appliance casings, automobile cover parts, and precision instrument components

Used as raw materials for deep processing (such as galvanizing, color coating), or used after being cut into plates, suitable for batch continuous production

Application Scenarios

Products with high requirements for surface and dimensional accuracy, such as refrigerator side panels, automobile door panels, and printer casings

Raw materials for automobile factory stamping lines, continuous production lines of home appliance enterprises, batch processing projects of metal products factories

Material

Covering low-carbon steel (SPCC), high-strength steel (DP steel), alloy structural steel, etc., consistent with the material of cold-rolled coils

Same as cold-rolled steel, with completely matching chemical composition and mechanical properties due to the same production process

Style

Flat plate shape, with smooth surface without scale, flat edges (after cutting), and can be coated (such as galvanized)

Coil shape, continuous coil form, with anti-rust oil and packaging film on the outer layer to prevent rust and scratches

Production Process Flow

Hot-rolled plate → pickling → cold rolling → annealing → temper rolling → cutting into flat plates (some need galvanizing/painting)

Hot-rolled plate → pickling → cold rolling → annealing → temper rolling → coiling into coils (one less cutting process than cold-rolled steel)

Quality Control

Focus on controlling surface roughness (Ra≤1.6μm), flatness, cutting tolerance (±0.01mm), and need to test formability (such as cup drawing value)

Control coil shape (tower shape ≤3mm), thickness uniformity of the same coil, and surface quality inspection (no pitting, scratches) consistent with cold-rolled steel

Usage and Installation Steps

Direct stamping, welding or bolt fixing, no need for surface pretreatment (anti-rust oil needs to be removed for welding)

First uncoiled by an uncoiler, cut and then used, pre-installation treatment is the same as cold-rolled steel

Other Details

Single sheets are easy to stack for storage, suitable for small-batch, multi-specification orders, and need to prevent scratches during transportation

Coil storage saves space, suitable for mass procurement, requires special coil racks for storage to avoid coil deformation
